Access covers

BV-GDZ
BV-GDZ
BV-GDZ

BV-GDZ

Watch

For covers that need to be opened from above and below, quickly and without particular effort, e.g. in underground passageways, in underground railways, power stations, telecommunication or military facilities etc.


Fact sheet

Fact sheet


Request

Material

Frame, cover and gas struts made of steel profiles, hot-dip galvanised

Features

- Odor- and waterproof
- Cover depth 5 cm
- Screwed
- To lift out of the ground

Load capacity

125 kN test load EN124

Articles

Pro.-No.

Light shaft dimensions (cm)

Outer dimensions (cm)

Weight unfilled (kg)

Tub depth (cm)

Installation height (cm)
c x d
A x B
BV-GDZ-066
60 x 60
73.5 x 75.15
30
5
8
BV-GDZ-086
80 x 60
93.5 x 75.15
38
5
8
BV-GDZ-088
80 x 80
93.5 x 95.15
44
5
8
BV-GDZ-106
100 x 60
113.5 x 75.15
44
5
8
BV-GDZ-108
100 x 80
113.5 x 95.15
50
5
8
BV-GDZ-110
100 x 100
113.5 x 115.15
58
5
8
